ClickHouse Connections

TablePro connects to ClickHouse over its HTTP interface (port 8123 by default), not the native TCP protocol. The driver ships inside the app; there is nothing to install.

​
Quick Setup

Click New Connection, select ClickHouse, enter host, port, credentials, and database, then click Save & Connect.

​
Connection Settings

SSL/TLS: Setting any non-Disabled SSL Mode switches the URL scheme to https. Required skips certificate verification, Verify CA validates against the supplied CA file, Verify Identity uses system default HTTPS trust (certificate chain plus hostname). Use Required for ClickHouse Cloud (port 8443). See SSL/TLS. For unencrypted HTTP to a remote server, use SSH tunneling.

​
Connection URL

See Connection URL Reference for all parameters.

​
Features

​
Database and Table Browsing

The sidebar lists all databases on the server. Expand one to see its tables, views, and materialized views. Press Cmd+K or click the database name in the toolbar to switch. For each table, TablePro shows:
  • Structure: Columns with ClickHouse data types, default expressions, and comments
  • Indexes: Data-skipping indices (minmax, set, bloom_filter, and others)
  • DDL: The full CREATE TABLE statement including engine and settings
  • Parts: Partition and part details from system.parts (rows, disk size, active status), with Optimize Table, Drop Partition, and Detach Partition actions
ClickHouse Parts tab showing partitions with Optimize, Drop, and Detach actions

The Parts tab with partition actions

​
EXPLAIN Variants

Click the Explain dropdown in the query editor to choose:

​
Server-side Query Cancellation

Cancelling a running query sends KILL QUERY to the server, stopping the query itself, not just the HTTP connection.

​
Server Dashboard

The Server Dashboard supports ClickHouse: active sessions, server metrics, and slow queries.

​
Data Editing

Edit cells, insert rows, and delete rows in the data grid. Edits are submitted as INSERT, ALTER TABLE ... UPDATE, and ALTER TABLE ... DELETE statements.
ClickHouse mutations (UPDATE and DELETE) are asynchronous. They run in the background and can take time on large tables. Check progress with SELECT * FROM system.mutations WHERE is_done = 0.

​
Export and Import

Export query results or table data to CSV, JSON, and other formats. Import data from CSV files. See Import and Export.

​
Troubleshooting

Connection refused: Check ClickHouse is listening on the HTTP port: curl http://localhost:8123/ping should return Ok.. Common port mix-up: 8123 is HTTP, 8443 is HTTPS, 9000 is native TCP (not used by TablePro). If the HTTP interface is disabled, check <http_port> in /etc/clickhouse-server/config.xml. Authentication failed (HTTP 403): Verify the username and password, that the user exists (SELECT name, auth_type FROM system.users), and that it has access to the target database (SHOW GRANTS FOR app_user). Connection timeout: Verify host, port, firewall rules, and, for cloud-hosted ClickHouse, that your IP is in the allowed list.

​
Known Limitations

  • No foreign keys or multi-statement transactions
  • No auto-increment; primary key and sorting key are immutable after creation
  • Structure editing supports add, modify, and drop columns, plus data-skipping indexes. Foreign keys and primary key changes are not available
  • UPDATE/DELETE run as asynchronous background mutations via ALTER TABLE
  • ClickHouse is designed for batch inserts, not single-row writes
  • A query with its own FORMAT clause (for example SELECT 1 FORMAT JSON) shows the server’s raw output in a single column instead of a parsed table
