Pairing

Pairing is how an extension gets a TablePro token without the user copying one by hand. The extension opens a tablepro://integrations/pair deep link, the user approves scopes and connections in TablePro, and the extension exchanges a one-time code for the token over localhost HTTP. The flow is PKCE-style: the extension generates a verifier, hashes it into a challenge, and TablePro releases the token only to the caller that presents the verifier. An app that intercepts the redirect cannot exchange the code.

Sequence

TablePro sheet asking to approve a pairing request with scope, connection, and expiry pickers — The pairing approval sheet

Extension steps

1. Generate a verifier and challenge

import { randomBytes, createHash } from "node:crypto";

function base64url(buffer: Buffer): string {
  return buffer.toString("base64").replace(/\+/g, "-").replace(/\//g, "_").replace(/=+$/, "");
}

const verifier = base64url(randomBytes(32));
const challenge = base64url(createHash("sha256").update(verifier).digest());

Keep the verifier in memory until the exchange step. Do not log it.

2. Open the pair deep link

Open tablepro://integrations/pair?client=...&challenge=...&redirect=...&scopes=.... Parameters are documented in the URL scheme reference.

3. Receive the code and exchange it

TablePro opens your redirect URL with a one-time code. For raycast:// redirects the code arrives as ?context={"code":"<uuid>"} (Raycast’s launch-context convention); for any other scheme it is a flat ?code=<uuid> query parameter. An error parameter instead of a code means the user denied the request; stop and show the description. Read the MCP port from ~/Library/Application Support/TablePro/mcp-handshake.json, then:

const port = await readHandshakePort();
const res = await fetch(`http://127.0.0.1:${port}/v1/integrations/exchange`, {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({ code, code_verifier: verifier }),
});
const { token } = await res.json();

The exchange endpoint requires no bearer auth. The single-use code plus the verifier is the auth.

4. Store the token

Store the token in the macOS Keychain. In Raycast, write it to a password preference, which is Keychain-backed. Do not keep it in LocalStorage or plain files.

What TablePro does on approval

The approval sheet shows the client name, a scope picker (defaults to the requested scope, downgradeable), a connections multi-select (defaults to all unless connection-ids was provided), and an expiry picker (defaults to never). The query parameters are a request, not a grant. On approve, TablePro:

Revokes any existing active token with the same client name. An extension that pairs again must replace its stored token; the old one stops working the moment the user approves.
Mints the token and holds the plaintext in memory as a pending exchange keyed by a UUID code, valid for 5 minutes. Only the SHA-256 hash plus salt reaches mcp-tokens.json.
Opens the redirect URL with the code.

At most 50 exchange codes can be pending at once. Beyond that, new pair requests fail until older codes expire.

Security properties

Property	How
Token is never in a URL	The token travels over localhost HTTP, not in a deep link.
Redirect interception is harmless	The intercepted `code` cannot be exchanged without the verifier.
Code is single-use	Successful exchange or 5-minute expiry deletes the pending exchange.
Plaintext token is not persisted by TablePro	Only the SHA-256 hash plus salt is saved to `mcp-tokens.json`.
User sees and approves scopes	The sheet shows what was requested, what is granted, and which connections.
User can revoke any time	Settings > Integrations > Authentication > Revoke.

Errors

Code	Meaning
`403 Challenge mismatch`	The verifier does not hash to the stored challenge.
`404 Pairing code not found`	The code does not exist or was already exchanged.
`410 Pairing code expired`	The pending exchange is older than 5 minutes.

A failed exchange is recorded in the activity log under the auth category with outcome denied. If the user clicks Deny, TablePro opens the redirect URL with error=denied and error_description=user_denied, wrapped in the context JSON for raycast:// redirects and appended as flat query parameters otherwise.

Implementing pairing in another extension

The flow is not Raycast-specific. Any client that can receive a callback can use it:

Generate a verifier and challenge.
Open tablepro://integrations/pair?... with a callback URL the OS can route back to you.
Read the MCP port from the handshake file.
POST { code, code_verifier } to /v1/integrations/exchange.
Store the returned token in the Keychain.

If the client cannot register a custom URL scheme, run a localhost HTTP server on a chosen port and pass http://127.0.0.1:<port>/callback as the redirect.
